Klipsch KPT-8060H surround speakers (medium/big rooms)

Met een hoge output die is ontworpen om middelgrote tot grote bioscopen te dekken, heeft de KPT-8060H de veelzijdigheid als een perfecte luidspreker voor traditionele tot hedendaagse multichannel digitale surround-formaten.

FREQUENCY RESPONSE1 (+/- 3 dB) 75 Hz – 20 kHz (–10 dB @ 49 Hz)

POWER HANDLING2 AES: 112 watts (30V) 40 Hz – 10 kHz

IEC: 190 watts (33.5V)

MAXIMUM SPL3 121.3 dB Continuous

127.3 dB Peak

SENSITIVITY4 98.5 dB @ 2.83V

COVERAGE Horizontal: 90° +/– 20° 2 kHz – 18 kHz

Vertical: 60° +20°/–15° 1.6 kHz – 20 kHz

DIRECTIVITY INDEX (DI) 8 dB +/- 1 dB 2.2 kHz – 20 kHz

DIRECTIVITY FACTOR (Q) 6.3 2 kHz – 20 kHz

NOMINAL IMPEDANCE 8 ohms, minimum 4.5 ohms @ 230 Hz

CROSSOVER FREQUENCY 1.77 kHz 12 dB/Octave LF 18 dB/Octave HF

COMPONENTS One K-81-ST 8" woofer

One K-103-TI 1” titanium compression

driver on a K-702 horn

INPUT CONNECTION Four point barrier strip

BRACKET SCREW PATTERN 4 screw: 2.75” (6.9cm) x 5” (12.7cm)

INCLUDED SCREWS (4) 1.125” (2.86cm) 1/4-20 x 1.25 UNC 2A

(4) .75” (1.9cm) 1/4-20 x .75 UNC 2A

ENCLOSURE MATERIAL ABS + 10% glass

GRILLE Powder-coated steel

HEIGHT 18.7” (47.5cm)

WIDTH Top: 14.7” (37.3cm)

Bottom: 13” (33cm)

DEPTH Top: 7.2” (18.3cm)

Bottom: 4.7” (11.9cm)

WEIGHT 20 lbs (9.07kg)

TILT Built-in 8° downward angle with 15°

angle option

SAFETY CABLE INSERT 3/8” 1/4-20 threaded
